| WELD ON END | |||||||
| CODE | D | E | A | B | C | ||
| LWOE525019D | 19 | 44 | 52 | 50 | 52 | ||
| LWOE675019D | 19 | 35 | 67 | 50 | 60 | ||
| LWOE675022D | 22.1 | 35 | 67 | 50 | 60 | ||
| LWOE675022DA | 22.1 | 35 | 67 | 50 | 56 | ||
| LWOE677022D | 22.1 | 35 | 67 | 70 | 60 | ||
| LWOE677522D | 22.1 | 35 | 67 | 75 | 58 | ||
| LWOE825528D | 28.4 | 45 | 82 | 55 | 70 | ||
| LWOE837925D | 25.4 | 38 | 83 | 79 | 70 | ||
| LWOE837928D | 28.4 | 38 | 83 | 79 | 70 | ||
| LWOE858028D | 28.4 | 45 | 85 | 80 | 70 | ||
| LWOE858022D | 22 | 45 | 85 | 80 | 70 | ||
| LWOE855028D | 28.4 | 35 | 85 | 80 | 70 | ||
| LWOE948628D | 28.4 | 45 | 94 | 86 | 94 | ||
| LWOE948638D | 38 | 45 | 94 | 86 | 94 | ||
| LWOE1008328D | 28.4 | 45 | 100 | 83 | 100 | ||
| LWOE1008337D | 37 | 45 | 100 | 83 | 100 | ||
| LWOE1008338D | 38 | 45 | 100 | 83 | 100 | ||
| WELD ON END WITH SLOT | |||||||
| CODE | d | D | A | B | C | E-SLOT | SIDE |
| WOE 84450240 | 28.4 | 45 | 76 | 85 | 95 | 28X45X95 | R |
| WOE 84450250 | 284 | 45 | 76 | 85 | 95 | 28X45X95 | L |
| WOE 87450080 | 37 | 445 | 94 | 90 | 95 | 28X45X95 | R |
| WOE 87450090 | 37 | 45 | 94 | 90 | 95 | 28X45X95 | L |
| WELD ON END (REPLACES URSUS) | |||||||
| CODE | D | E | A | B | C | ||
| LWOE714028UR | 28.4 | 45 | 71 | 40 | 70 | ||
